| A continuous production and pumping system |
| Main supply line: (III ~) 220/440 V 50/60 Hz (1) |
| Nominal power: 10 Kw. (13,5 C.V.) |
| Power consumption when charge: 7,5 Kw. |
| Nominal Amperes: 23 A/380 V. 40 A/220 V. |
| Amperes consumption when charge: 14 A/380 V. 24 A/220 V. |
| Electric generator needed (when there is not main supply line in work): 20 KVA |
| Weight in Kg of towed machine |
Total machine: 608. In curb weight (with all auxiliary parts except outlet Cellular Concrete
hoses and water tank) |
| Total admissible as maximum: 750. Total payload: 142. Maximum on quick ball: 75 |
| Weight in Kg of mixer |
| Total with all its elements (filter and grid): 142 |
| Weight in Kg of outlet C.C. hoses |
| 44 (every piece; it has 2 pieces of 40 m each one) |
| Weight in Kg of the rest of elements |
| 77 (water tank 1.000 l and splash-back protection plate) |
