| Mechanical Safety Elements |
| Hopper lid protects against entry of foreign objects |
| Hopper grille protects against entry of unwanted elements |
| Electric Safety Elements |
| Electronically controlled self- cleaning system |
| Electric components protected with grounded |
| Protection against short circuiting on all lines |
| Engine overload protection |
| Low voltage operation and marking: 24 V. |
| Activation Elements |
| Stop-locking-run selector |
| Regulation and Signalling Elements |
| Dosage of product (Programming of 0,1 by 0,1 Kg/h) |
| Product density ( Programming of 0,01 by 0,01 Kg/l) |
| Signalling electronic circuit testing |
| Signalling engine running |
| Signalling overload engine |
| Support Structure Elements |
| Hooper with grille |
| Telescopic post, height adjustable from 1,230-1,830 mm. |
| High stability support bracket with wheels and brakes |
| Lockable electric switchboard |
Conveyor tube in special technical plastic for foodstuffs, 90 cm long
(other lengths optional) |
| Materials and Finishes |
Stainless steel. High resistance to any corrosive product in all parts and components
of the machine. Other components made of technical plastic and special aluminum. |
| Certification, Standards and Guarantee |
Each machine is accompanied by European Certificate (E.C.) manufacturer´s
approval certificate where directives in industrial application guidelines for application
and harmonized regulation for compliance. All of the elements are guaranteed, of the
highest quality, and meet all the legal requirements in force. |
